P2 Indoor Led Display (Custom Size)

The Suitch On P2 Indoor LED Display (Custom Size) from Suitch On Innovation is a high-performance digital display solution designed to deliver ultra-fine visuals, vivid color accuracy, and seamless modular flexibility for professional indoor environments.

With a 2mm pixel pitch (P2), this display ensures exceptional image clarity and sharpness, making it ideal for applications such as corporate lobbies, retail stores, control rooms, digital advertising walls, auditoriums, and event backdrops.

The custom-size configuration allows you to create displays that perfectly fit your architectural space or design needs — whether it’s a small wall-mounted screen or a large-format video wall.

Featuring high refresh rate technology, wide viewing angles, and superior brightness, this LED display guarantees excellent visual performance even under various lighting conditions. Built with premium die-cast aluminum cabinets, it offers seamless splicing, easy installation, and long-term durability.

⚙️ Technical Information

Model: P2 Indoor LED Display (Custom Size)
Brand: Suitch On Innovation
Category: Indoor LED Video Wall / Digital Display

💡 Display Specifications

  • Pixel Pitch: 2mm (P2)
  • LED Type: SMD 3-in-1 (Surface Mounted Device)
  • Brightness: 800–1200 cd/m² (Adjustable)
  • Contrast Ratio: 5000:1
  • Refresh Rate: ≥ 1920 Hz
  • Viewing Angle: 140° (Horizontal) / 120° (Vertical)
  • Color Temperature: 3200K – 9300K Adjustable
  • Resolution: Custom, Based on Display Size
  • Display Size: Custom Configurable
  • Cabinet Material: Die-Cast Aluminum
  • Cabinet Size: Customizable Modules (e.g., 640mm × 480mm)
  • Module Size: 256mm × 128mm

⚙️ Electrical Specifications

  • Input Voltage: AC 100–240V (50/60 Hz)
  • Power Consumption (Avg): 250 W/m²
  • Power Consumption (Max): 600 W/m²
  • Driving Mode: 1/32 Scan
  • Control System: Novastar / Colorlight / Linsn Compatible
  • Data Transmission: CAT6 / Fiber Optic Supported

🧱 Build & Design

  • Installation Type: Wall-Mounted / Hanging / Floor Stand
  • Frame: Aluminum Die-Cast Body
  • Maintenance: Front / Rear Access Available
  • Protection Level: IP31 (Indoor Use)
  • Weight: Approx. 7–9 kg per Cabinet
  • Design: Ultra-Slim, Seamless Modular Build

🌡️ Operating Environment

  • Temperature Range: -10°C to +45°C
  • Humidity Range: 10% – 90% (Non-Condensing)

🛠️ Features

  • Ultra-Fine Pixel Pitch for Superior Clarity
  • Seamless Panel Splicing with No Visible Gaps
  • High Refresh Rate for Flicker-Free Video Playback
  • Customizable Screen Size and Aspect Ratio
  • Easy Installation and Maintenance
  • Energy-Efficient Power Design
  • Long Lifespan: ≥ 100,000 Hours

📦 Applications

  • Corporate Offices & Boardrooms
  • Indoor Advertising & Retail Spaces
  • Control Rooms & Command Centers
  • Auditoriums & Event Venues
  • Shopping Malls & Airports
  • Educational & Religious Institutions

🛡️ Warranty

  • 2-Year Manufacturer Warranty from Suitch On Innovation
.
