⚙️ Technical Information

Model: SBA015
Brand: Suitch On
Type: Wall Mount Digital Signage (Touch / Non-Touch)

🖥️ Display Specifications

• Display Size: 60 Inches
• Display Type: LED Panel
• Aspect Ratio: 16:9
• Contrast Ratio: 10,000:1
• Resolution: Full HD 1920 × 1080 (Optional 4K Upgrade)
• Brightness: 400–450 nits
• Viewing Angle: 178° (H/V)
• Response Time: < 8 ms

🧠 System Specifications

• RAM: 1 GB
• Storage: 4 GB (Expandable via USB)
• Processor: Quad-Core (Android version)
• Operating System: Android / Plug & Play Media System (Customizable)

🔊 Audio & Multimedia

• Speaker: Yes (Built-in Stereo Speakers)
• Supported Video Formats: MP4, AVI, MKV, MOV
• Supported Image Formats: JPEG, PNG, BMP
• Supported Audio Formats: MP3, AAC, WAV

🔌 Connectivity

• USB Ports: 2
• HDMI Port: 1 (Optional)
• LAN / Wi-Fi: Optional (for smart models)
• SD Card Slot: Optional

🧱 Build & Design

• Frame Material: MS Iron (Powder-coated finish)
• Front Glass: 5 mm Toughened Glass
• Mount Type: Wall Mount Design
• Body Color: Matte Black (Custom colors available)
• Installation: Wall Bracket Mount (included)

⚙️ Power & Environment

• Input Voltage: 100 – 240 V AC (50/60 Hz)
• Power Consumption: ≤ 100 W
• Operating Temperature: 0 °C – 50 °C
• Operating Humidity: 10 % – 90 % RH (non-condensing)

🧰 Touch (Optional)

• Touch Type: Capacitive 10-Point Touch
• Response Time: < 10 ms
• Durability: 50 Million Touches Lifespan

📦 Package Includes

• 1 × Suitch On SBA015 Digital Signage Unit
• 1 × Wall Mount Bracket Set
• 1 × Power Cable
• 1 × Remote Control (for Non-Touch model)
• 1 × User Manual

🛡️ Warranty

• 1 Year Manufacturer Warranty (against manufacturing defects)
