SBA025 43-Inch L-Type Digital Signage(Touch/Non-Touch)

The Suitch On SBA025 43-Inch L-Type Digital Signage is a sleek, next-generation display solution designed for retail, hospitality, and business environments that demand premium visual performance and durability. Featuring a modern L-shaped design, it combines aesthetics with functionality, providing an engaging digital experience for both customers and visitors.

Equipped with a Full HD LED panel, MS Iron frame, and 5mm toughened glass, the SBA025 ensures long-term reliability and stunning visual quality. The 10,000:1 contrast ratio and 16:9 aspect ratio deliver rich, vibrant colors with exceptional clarity. Available in both Touch and Non-Touch variants, it’s ideal for interactive kiosks, advertising displays, or information panels.

Powered by an Android-based system with 1GB RAM and 4GB storage, it supports smooth multimedia playback and user-friendly operation. Built-in speakers provide clear and immersive sound for videos and presentations, making the SBA025 a complete all-in-one signage solution.

⚙️ Technical Information

Model: SBA025
Brand: Suitch On
Product Type: L-Type Digital Signage (Touch/Non-Touch)

🖥️ Display Specifications

  • Display Size: 43 Inches
  • Display Type: LED Backlit Display
  • Resolution: 1920 × 1080 (Full HD)
  • Contrast Ratio: 10,000:1
  • Aspect Ratio: 16:9
  • Brightness: 400 nits (typical)
  • Viewing Angle: 178° (H/V)
  • Response Time: 6–8 ms

Touch Panel (For Touch Model Only)

  • Touch Technology: Capacitive / Infrared Multi-Touch
  • Touch Points: 10 points
  • Touch Accuracy: ±1mm
  • Touch Glass: 5mm Toughened Anti-Glare Glass
  • Touch Durability: 50 million touches

🧠 System Specifications

  • Operating System: Android 7.1 / 9.0 (Upgradable)
  • Processor: Quad-Core ARM Cortex
  • RAM: 1GB
  • Storage: 4GB
  • Wi-Fi: Supported
  • LAN Port: Optional
  • App Support: Compatible with Android applications for media and CMS control

🔊 Audio & Multimedia

  • Speakers: Built-in (2 × 10W)
  • Audio Output: 3.5mm / HDMI
  • Supported Media Formats: MP4, AVI, MKV, MP3, JPEG, PNG, PDF

🔌 Connectivity Ports

  • USB Ports: 2
  • HDMI Input: 1
  • VGA Port: 1
  • LAN Port: 1 (Optional)
  • Audio In/Out: Yes

🧱 Build & Design

  • Frame Material: MS Iron Frame
  • Front Glass: 5mm Toughened Glass
  • Design Type: L-Type Freestanding Design
  • Color: Matte Black (Customizable)
  • Mounting Type: Floor Standing or Wall-Mount (Optional)

⚙️ Power & Environmental Specs

  • Voltage: 100–240V AC, 50/60Hz
  • Power Consumption: ≤120W
  • Operating Temperature: 0°C – 45°C
  • Operating Humidity: 10% – 90% RH

📦 Package Includes

  • 1 × 43-Inch L-Type Digital Signage
  • 1 × Power Cable
  • 1 × Remote Control
  • 1 × User Manual

🛡️ Warranty

  • 1 Year Manufacturer Warranty (against manufacturing defects)
.
