⚙️ Technical Information

Model: P1.5 Indoor LED Display
Brand: Suitch On Innovation
Category: LED Display Solutions

🔍 Display Specifications

• Pixel Pitch: 1.5 mm
• LED Type: SMD (Surface Mounted Device)
• Display Type: Indoor Full-Color LED
• Brightness: ≥ 800 nits
• Refresh Rate: ≥ 3840 Hz
• Viewing Angle: 160° (Horizontal) / 140° (Vertical)
• Contrast Ratio: 5000:1
• Aspect Ratio: Customizable (Based on Configuration)
• Resolution: High Definition (HD Ready / Full HD Based on Size)
• Module Size: 320 mm × 160 mm (Typical)
• Cabinet Size: Custom (Seamless Modular Panels)

⚡ Electrical Parameters

• Operating Voltage: AC 110–230 V
• Power Consumption (Avg): 300–400 W/m²
• Power Consumption (Max): 800 W/m²
• Input Signal: HDMI, DVI, VGA, USB, LAN
• Control System: NovaStar / Colorlight / Linsn Compatible

🌡️ Operating Environment

• Operating Temperature: –10°C to +50°C
• Operating Humidity: 10% – 90% RH (Non-Condensing)
• Installation Type: Wall-Mounted / Hanging / Floor-Stand

🧱 Mechanical Features

• Cabinet Material: Die-Cast Aluminum
• Cabinet Weight: Lightweight (~8–12 kg per panel)
• Maintenance: Front & Rear Accessible
• Seam: Seamless Display with Fine Pixel Alignment

🧠 Performance Features

• Ultra HD Visual Quality for Short Viewing Distances
• High Refresh Rate for Flicker-Free Broadcast and Camera Use
• True-to-Life Color Reproduction (Wide Gamut LED)
• Intelligent Brightness Adjustment for Energy Saving
• Easy Control via Software or Network

📦 Package Includes

• LED Display Modules (As per Configuration)
• Power Supply Units
• Control System
• Data Cables & Connectors
• Installation Accessories
• User Manual

🛡️ Warranty

• 3-Year Manufacturer Warranty
• Lifetime Technical Support
