⚙️ Technical Information

Model: Suitch On 6 Meter Automatic Boom Barrier
Brand: Suitch On Innovation
Category: Access Control & Security Automation

⚡ Specifications

• Arm Length: 6 Meters (Aluminum Octagonal Arm)
• Operating Voltage: AC 230 V ± 10%
• Motor Power: 120 W – 200 W (depending on variant)
• Boom Opening / Closing Time: 3 – 6 Seconds Adjustable
• Drive Mechanism: Electromechanical with Crank & Rod System
• Duty Cycle: 100% (Continuous Operation)
• Protection Level: IP 54
• Operation Mode: Automatic / Manual Override
• Frequency of Use: > 10,000 cycles per day

🌡️ Operating Environment

• Operating Temperature: –20 °C to +50 °C
• Humidity Range: 5 % – 90 % RH (Non-Condensing)

⚙️ Control & Integration

• Control Interface: RFID, Remote Control, Push Button, Loop Detector, Card Reader, Access Controller, or App Integration
• Communication: Dry Contact / RS485 / TCP (optional)
• Auto Reverse Function: Yes (safety sensor supported)
• Manual Release: Available for power failure operation

🧱 Build & Design

• Housing Material: Powder-Coated MS Cabinet
• Arm Material: Aluminum Alloy – Reflective Finish
• Arm Type: Straight / Foldable / Fence (optional)
• Dimensions (Cabinet): Approx. 350 × 300 × 1000 mm
• Color: Orange / Yellow (customizable)

🛡️ Safety Features

• Auto-Reverse on Obstruction
• Manual Override for Emergency Operation
• Overheat Protection Motor
• Soft Start & Stop Mechanism
• Optional Safety Photocell Integration

📦 Package Includes

• 1 × Boom Barrier Unit (6 m)
• 1 × Control Panel with Key Set
• 1 × Boom Arm Assembly
• 1 × User Manual & Mounting Accessories

🕒 Warranty

• 1-Year Manufacturer Warranty from Suitch On Innovation
