Glass Door Sensor 4.2 mtr

The Suitch On Glass Door Sensor (4.2 Meter Range) by Suitch On Innovation is a high-precision, intelligent motion detection solution designed specifically for automatic glass door systems. It ensures smooth, safe, and efficient door operation by accurately detecting human movement and triggering door activation without physical contact.

Built using infrared motion detection technology, this sensor provides reliable performance even under varying lighting conditions and environmental changes. With a detection range of up to 4.2 meters, it ensures quick and responsive door activation for both commercial and residential use.

Ideal for offices, malls, hotels, hospitals, and smart buildings, the sensor enhances accessibility, energy efficiency, and hygiene by enabling completely touch-free entry and exit.

⚙️ Technical Information

Model: Glass Door Sensor 4.2 Mtr
Brand: Suitch On Innovation
Category: Door Automation / Smart Sensor

Specifications

  • Detection Range: Up to 4.2 meters
  • Technology: Infrared Motion Detection
  • Detection Angle: 90° – 120° Adjustable
  • Sensing Type: Active Infrared / Microwave (Optional)
  • Operating Voltage: 12–36 V DC / 12–30 V AC
  • Response Time: < 0.5 seconds
  • Mounting Height: 2.2 – 3.0 meters (Adjustable)
  • Installation: Surface Mount (Ceiling or Door Frame)
  • Indicator: LED Status Light (Detection & Power)

🌡️ Operating Environment

  • Operating Temperature: -20°C to +55°C
  • Operating Humidity: 0% to 90% RH (Non-Condensing)
  • Protection Grade: IP42 (Dust & Splash Resistant)

🧱 Build & Design

  • Housing Material: ABS Fire-Retardant Plastic
  • Finish: Matte Black / White
  • Cable Length: 4.2 meters
  • Weight: Approx. 150g
  • Mounting Bracket: Adjustable for Angular Alignment

⚙️ Features

✅ Advanced Infrared Sensor for Accurate Detection
✅ Long Detection Range – Up to 4.2 Meters
✅ High Sensitivity with Fast Response Time
✅ Compatible with Automatic Sliding Glass Doors
✅ Easy Installation on Door Frames or Ceilings
✅ Energy Efficient – Operates Only When Motion Detected
✅ Enhances Safety and Hygiene through Contactless Operation

📦 Package Includes

  • 1 × Suitch Glass Door Sensor (4.2 mtr Cable)
  • 1 × Mounting Bracket Set
  • 1 × User Manual

🛡️ Warranty

  • 1-Year Manufacturer Warranty from Suitch On Innovation
.
