86-Inch Interactive Panel

The Suitch On 86-Inch Interactive Panel is the ultimate large-format smart display, designed to empower education, enterprise collaboration, and digital presentations with unmatched clarity and responsiveness. Featuring a 4K Ultra HD LED panel, 20-point multi-touch capability, and an integrated Android system, this panel transforms classrooms and meeting rooms into dynamic, interactive environments.

Its expansive 86-inch display provides an immersive viewing experience, ideal for group learning, video conferencing, and creative brainstorming. Built with 4mm anti-glare toughened glass and a durable aluminum alloy frame, the panel ensures both safety and longevity.

With wireless screen sharing, dual operating system support (Android + Windows via OPS), and integrated high-fidelity speakers, the Suitch On 86-Inch Interactive Panel offers everything you need for seamless collaboration, interactivity, and engagement — all in one device.

⚙️ Technical Information

Model: SIP86
Brand: Suitch On
Product Type: Interactive Touch Panel

🖥️ Display Specifications

  • Display Size: 86 Inches
  • Display Type: LED Backlit Panel
  • Resolution: 3840 × 2160 (4K UHD)
  • Aspect Ratio: 16:9
  • Contrast Ratio: 10,000:1
  • Brightness: 450–500 nits
  • Viewing Angle: 178° (H/V)
  • Response Time: <8ms
  • Refresh Rate: 60Hz

Touch Technology

  • Touch Type: Infrared / Capacitive 20-point Multi-Touch
  • Touch Accuracy: ±1mm
  • Response Speed: <10ms
  • Touch Glass: 4mm Anti-Glare Toughened Glass
  • Touch Durability: 50 million touches

🧠 System Specifications (Built-in Android)

  • Operating System: Android 11 (Upgradable)
  • Processor: Quad-Core Cortex A55
  • RAM: 4GB
  • Storage: 32GB
  • GPU: Mali G52
  • Network: Wi-Fi / Ethernet
  • Optional OPS PC Slot: Available (Supports Intel i3/i5/i7 Windows System)

🔊 Audio & Multimedia

  • Speakers: 2 × 15W Built-in Stereo Speakers
  • Audio Output: 3.5mm / HDMI Audio
  • Supported Formats: MP4, AVI, MKV, JPEG, PNG, MP3, AAC

🔌 Connectivity Ports

  • USB Ports: 4 × USB 3.0
  • HDMI: 2 × HDMI Input, 1 × HDMI Output
  • VGA: 1 × VGA Input
  • LAN Port: 1 × RJ45
  • Audio In/Out: Yes
  • RS232 Control Port: Yes
  • OPS Slot: Yes

🧱 Build & Design

  • Frame Material: Aluminum Alloy
  • Front Glass: 4mm Toughened Anti-Glare Glass
  • Bezel Color: Matte Black
  • Mounting Type: Wall Mount / Mobile Stand Compatible
  • Cooling System: Silent Heat Dissipation

⚙️ Power & Environment

  • Voltage: 100–240V AC, 50/60Hz
  • Power Consumption: ≤ 250W
  • Operating Temperature: 0°C – 45°C
  • Operating Humidity: 10% – 90% RH

📦 Package Includes

  • 1 × 86-Inch Interactive Panel
  • 1 × Remote Control
  • 1 × Power Cable
  • 1 × Wall Mount Kit
  • 2 × Stylus Pens
  • 1 × User Manual

🛡️ Warranty

  • 1 Year Manufacturer Warranty (against manufacturing defects)
.
